Only few typical products of this series are shown in the following pages. EHC is capable of making other customized design and manufacturing per user request.
Specifications and Parameters:
Model |
Primary Current |
Output Voltage |
Sampling resistance |
Unbalanced current |
EHC-ZCT106 |
5~300mA |
5~300mV |
1KΩ |
<2mA@125A |
EHC-ZCT160 |
100mA |
7mV |
50Ω |
<5mA@160A |
EHC-ZCT250 |
100mA |
7mV |
50Ω |
<5mA@250A |
EHC-ZCT630 |
100mA |
7mV |
50Ω |
<5mA@630A |
Dimension table:
Model |
φA(mm) |
φB(mm) |
C(mm) |
EHC-ZCT106 |
8.5 |
22.6 |
10 |
EHC-ZCT160 |
28.5 |
41 |
10 |
EHC-ZCT250 |
37 |
54 |
11 |
EHC-ZCT630 |
57 |
76 |
16 |
EHC-ZCT106 |
EHC-ZCT160/250/630 |
